Model 60063 Stainless Steel, Welded Seal S-Beam Load Cell
The Sensortronics Model 60063 Stainless Steel S-Type Load Cell is an NTEP approved load cell for tension & compression with IP68 sealing for harsh environments. Perfect for bin, hopper, belt conveyor scales, level & inventory monitoring, food & beverage processing, chemical & pharmaceutical applications, and force measurement. FM approved and designed for easy mounting.
$108.75
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | $103.75 |
| 11 - 15 | $10.00 | $98.75 |
| 16 - 20 | $15.00 | $93.75 |
Payment Methods:
Description
Title :- Model 60063 Stainless Steel, Welded Seal S-Beam Load Cell
Brand :- Sensortronics
DESCRIPTION
The Model 60063 is a stainless steel S-Type load cell. Its welded sealing, combined with high accuracy, make this load cell ideally suited for a wide range of applications of process weighing and force measurement.
Approvals included NTEP III 5000d single and NTEP IIIL10000d multiple. Also available are versions approved for hazardous areas – FM I, II, III Division 1.
FEATURES
• Rated capacities of 500 to 20,000 pounds
• Stainless steel, welded seal construction
• Integrated loading brackets
• Compatible with TCM tension mounting hardware
• Designed for single or multiple load cell applications
• Trade certified for NTEP Class IIIL: 10000d and
III: 5000d
• Sensorgage™ sealed to IP68 standards
• Factory Mutual System Approved for Classes I, II, III;
Divisions 1 and 2; Groups A through G.
Also, non-incendive ratings (No barriers!)
• Optional
– Mounting and loading accessory hardware available
APPLICATIONS
• Hostile environments: Food and beverage processing
Chemical and plastics processing
Pharmaceutical and biomedical
• Bin, hopper and belt conveyor scales
• Level and inventory monitoring
• Tension and compression measurements
