Model 60001 S-Beam Load Cell
Sensortronics Model 60001 S-Beam Load Cell – NTEP Class III & IIIL approved tension-compression load cell with IP67 sealing. Ideal for tank, bin, hopper weighing, truck scale conversions, force measurement, and hanging scales. FM-approved for hazardous areas.
Price range: $87.55 through $234.61
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | - |
| 11 - 15 | $10.00 | - |
| 16 - 20 | $15.00 | - |
Payment Methods:
Description
Title :- Model 60001 S-Beam Load Cell
Brand :- Sensortronics
DESCRIPTION
The Model 60001 is a tension-compression load cell with a humidity-resistant coating and shielded cables, which enable its use in harsh environments while maintaining operating specifications. Additional sense wires compensate for changes in lead resistance due to temperature change and/or cable extension.
Ideally suited for lever conversions, hanging scales, force measurement and a wide range of other industrial applications. Nickel-plated for outstanding corrosion resistance.
FEATURES
• Rated capacities of 25 to 20,000 pounds,
50 kilograms to 10 metric tonnes
• Designed for single or multiple load cell applications
• Constructed of high quality alloy tool steel
• Nickel plated for outstanding corrosion resistance
• Sensorgage™ sealed to IP67 standards
• Trade certified for NTEP Class III: 5000d, IIIL:
10000d and OIML R-60 3000d available
• Factory Mutual System Approved for Classes I, II, III;
Divisions 1 and 2; Groups A through G.
Also, non-incendive ratings (No barriers!).
• Optional
– Stainless steel version is Model 60050
– EDOC option available; product appearance will differ
from the photograph due to coating
APPLICATIONS
• Tank, bin and hopper weighing
• Level and inventory monitoring
• Truck scale conversions
• Tension and compression measurements
