50kg Load Cell – Model 1130 Stainless Steel Single-Point Load Cell
$440.78
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | $435.78 |
| 11 - 15 | $10.00 | $430.78 |
| 16 - 20 | $15.00 | $425.78 |
Payment Methods:
Description
Accurate, Durable, and High-Performance Weighing Solution
The 50kg Load Cell – Model 1130 from Tedea-Huntleigh is a low-profile, stainless steel single-point load cell designed for precision weighing in demanding industrial and commercial environments. Ideal for bench and platform scales, packaging systems, and process weighing equipment, this load cell provides reliable and repeatable measurements with exceptional stability.
Key Features & Benefits:
- Capacity: 50 kg (also available in 7–100 kg variants)
- Stainless Steel Construction: Durable and corrosion-resistant for long-lasting performance
- Single-Point 400 × 400 mm Platform Compatibility: Easy integration into standard weighing platforms
- Mounting Thread Type: MT – secure and simple installation
- Environmental Protection: IP66 rated for dust and water resistance
- Precision Engineering: Ideal for applications requiring high accuracy
Applications:
- Bench and platform scales
- Packaging machinery
- Industrial process weighing
Limitations:
- Not ATEX/FM approved – unsuitable for hazardous or explosive environments
Smart Tip: The Model 1130 is perfect for industrial setups needing compact, robust, and highly accurate load cells.
Description
The Model 1130 is a low-profile stainless steel single point load cell ideally designed for direct mounting in bench and platform scales, packaging and process weighing equipment, and is built to perform in demanding environments.
The small physical size, combined with high accuracy and low cost, makes this load cell ideally suited for low profile bench and counting scales. A special humidity resistant protective coating assures long-term stability over the entire compensated temperature range.
Constructed in stainless steel, this high accuracy load cell is approved to stringent approval standards, e.g., OIML and NTEP.
The two additional sense wires feed-back the voltage reaching the load cell. Complete compensation of changes in lead resistance due to temperature change and/or cable extension, is achieved by feeding this voltage into the appropriate electronics.
Features
- Capacities 7–100 kg
- Stainless steel construction
- Single-point 400 × 400 mm platform
- OIML R60 and NTEP approved
- IP66 protection
- Available with metric and UNC threads
Options
- ATEX, FM and IECEx approvals available
Certifications
| Parameter | Value | Unit |
|---|---|---|
| Rated capacity (kg) | 7, 10, 15, 20, 30, 50, 75, 100 | kg |
| NTEP/oiml accuracy class | NTEP | Non-Approved | C3 | |
| Max. no. of intervals (n) | 4000 single | 1000 | 3000 | |
| Rated output R.O | 2.0 | mV/V |
| Rated output tolerance | 0.2 | ±%mV/V |
| Zero balance | 0.2 | ±%FSO |
| Creep error | 0.0015 | 0.0500 | 0.0200 | ±%FSO |
| Temp. effect on sensitivity | 0.0030 | 0.0100 | 0.0023 | ±%FSO/F |
| Temp. effect on min dead load output | 0.0008 | 0.0030 | 0.0010 | ±%FSO/F |
| Ultimate over load | 300 | % of R.C |
| Excitation voltage | 10 | VDC or VAC RMS |
| Max. excitation voltage | 15 | VDC or VAC RMS |
| Input resistance | 385±15 | Ω |
| Output resistance | 350±3 | Ω |
| Insulation resistance | >2000 | MΩ |
| Environmental protection | IP66 |
- FSO – Full Scale Output
Application
- Demanding environment small platforms
- Demanding environment check weighing
