100kg Load Cell – Model 1130 Stainless Steel Single-Point Load Cell
$777.85
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | $772.85 |
| 11 - 15 | $10.00 | $767.85 |
| 16 - 20 | $15.00 | $762.85 |
Payment Methods:
Description
Durable and Precise Load Cell for Industrial and Commercial Weighing
The 100kg Load Cell – Model 1130 from Tedea-Huntleigh is a low-profile, stainless steel single-point load cell engineered for bench and platform scales, packaging systems, and process weighing equipment. Designed to operate in demanding environments, this load cell delivers accurate, stable, and repeatable measurements, making it ideal for industrial applications requiring reliability and precision.
Key Features & Benefits:
- Capacity: 100 kg (available in 7–100 kg variants)
- Construction: Stainless steel for superior durability, corrosion resistance, and long-lasting performance
- Platform Compatibility: Single-point 400 × 400 mm – perfect for standard bench and platform scales
- Mounting Thread Type: MT – easy and secure installation
- Environmental Protection: IP66 rated for dust and water ingress protection
- Precision Engineering: Ideal for packaging, industrial, and commercial weighing applications
Applications:
- Bench and platform scales
- Packaging machinery
- Industrial process weighing
Limitations:
- Not ATEX/FM approved – unsuitable for explosive or hazardous environments
Smart Tip: The Model 1130 is perfect for applications needing compact, high-precision, and durable load cells in demanding industrial settings.
Description
The Model 1130 is a low-profile stainless steel single point load cell ideally designed for direct mounting in bench and platform scales, packaging and process weighing equipment, and is built to perform in demanding environments.
The small physical size, combined with high accuracy and low cost, makes this load cell ideally suited for low profile bench and counting scales. A special humidity resistant protective coating assures long-term stability over the entire compensated temperature range.
Constructed in stainless steel, this high accuracy load cell is approved to stringent approval standards, e.g., OIML and NTEP.
The two additional sense wires feed-back the voltage reaching the load cell. Complete compensation of changes in lead resistance due to temperature change and/or cable extension, is achieved by feeding this voltage into the appropriate electronics.
Features
- Capacities 7–100 kg
- Stainless steel construction
- Single-point 400 × 400 mm platform
- OIML R60 and NTEP approved
- IP66 protection
- Available with metric and UNC threads
Options
- ATEX, FM and IECEx approvals available
| Parameter | Value | Unit |
|---|---|---|
| Rated capacity (kg) | 7, 10, 15, 20, 30, 50, 75, 100 | kg |
| NTEP/oiml accuracy class | NTEP | Non-Approved | C3 | |
| Max. no. of intervals (n) | 4000 single | 1000 | 3000 | |
| Rated output R.O | 2.0 | mV/V |
| Rated output tolerance | 0.2 | ±%mV/V |
| Zero balance | 0.2 | ±%FSO |
| Creep error | 0.0015 | 0.0500 | 0.0200 | ±%FSO |
| Temp. effect on sensitivity | 0.0030 | 0.0100 | 0.0023 | ±%FSO/F |
| Temp. effect on min dead load output | 0.0008 | 0.0030 | 0.0010 | ±%FSO/F |
| Ultimate over load | 300 | % of R.C |
| Excitation voltage | 10 | VDC or VAC RMS |
| Max. excitation voltage | 15 | VDC or VAC RMS |
| Input resistance | 385±15 | Ω |
| Output resistance | 350±3 | Ω |
| Insulation resistance | >2000 | MΩ |
| Environmental protection | IP66 |
- FSO – Full Scale Output
- All specifications subjects to change whithout notice.
Application
- Demanding environment small platforms
- Demanding environment check weighing
