Model- 9010 Self-Contained Weighing Module
Tedea-Huntleigh Model 9010 Self-Contained Weighing Module – High-speed, fluid damping, IP65-rated load cell for multihead weighers, check weighers, grading & sorting machines, and dynamic weighing. Shock-resistant, overload-protected, fast-settling, OIML & FM approved, with additional breather tube for dust protection.
Price range: $234.61 through $256.54
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | - |
| 11 - 15 | $10.00 | - |
| 16 - 20 | $15.00 | - |
Payment Methods:
Description
Title :- Model- 9010 Self-Contained Weighing Module
Brand :- Tedea-Huntleigh
DESCRIPTION
The Model 9010 is a self-contained weighing module for use in repeated shock-loading applications or where fast weighing and settling times are required, such as multi head weighers, check weighers and other static and dynamic weighing applications characterized by sudden or impact loading.
The Model 9010’s unique fluid damping system allows the load cell to be used in applications that previously required the use of LVDT’s or similar types of measuring devices.
The Model 9010 has a unique adjustable tare load cancellation feature which brings load cell adaptability into check weighing and grading applications.
The two additional sense wires feed back the voltage reaching the load cell. Complete compensation of changes in lead resistance, due to temperature change and/or cable extension, is achieved by feeding this voltage into the appropriate electronics.
FEATURES
• Capacities 3–90 kg
• Unique adjustable tare load cancelling mechanism
• Highly effective viscous damping
• 6 Built-in overload limit stops in three directions
• Weighing speed is much faster than standard load cell
• IP65 protection
• Optional
– Stainless steel version
– IP66 with additional breather tube
– OIML and FM approvals available
