7kg Load Cell – Model 1130 Stainless Steel Single-Point Load Cell
$440.78
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | $435.78 |
| 11 - 15 | $10.00 | $430.78 |
| 16 - 20 | $15.00 | $425.78 |
Payment Methods:
Description
Compact, Durable, and Precise Load Cell for Industrial and Commercial Weighing
The 7kg Load Cell – Model 1130 from Tedea-Huntleigh is a low-profile stainless steel single-point load cell designed for bench and platform scales, packaging systems, and process weighing equipment. Engineered for demanding environments, this load cell provides accurate, stable, and repeatable measurements even in challenging industrial applications.
Key Features & Benefits:
Capacity: 7 kg (available in 7–100 kg variants)
Construction: Stainless steel for corrosion resistance and long-term durability
Platform Compatibility: Single-point 400 × 400 mm – perfect for compact scales
Mounting Thread Type: MT – ensures secure and easy installation
Environmental Protection: IP66 rated, fully protected against dust and water ingress
Precision Engineering: Ideal for industrial, commercial, and packaging weighing applications
Applications:
Bench and platform scales
Packaging machinery
Process and industrial weighing
Limitations:
Not ATEX/FM approved – not suitable for explosive or hazardous environments
Smart Tip: The Model 1130 is perfect for applications needing a compact, precise, and durable load cell for small-capacity weighing.
Description
The Model 1130 is a low-profile stainless steel single point load cell ideally designed for direct mounting in bench and platform scales, packaging and process weighing equipment, and is built to perform in demanding environments.
The small physical size, combined with high accuracy and low cost, makes this load cell ideally suited for low profile bench and counting scales. A special humidity resistant protective coating assures long-term stability over the entire compensated temperature range.
Constructed in stainless steel, this high accuracy load cell is approved to stringent approval standards, e.g., OIML and NTEP.
The two additional sense wires feed-back the voltage reaching the load cell. Complete compensation of changes in lead resistance due to temperature change and/or cable extension, is achieved by feeding this voltage into the appropriate electronics.
Features
- Capacities 7–100 kg
- Stainless steel construction
- Single-point 400 × 400 mm platform
- OIML R60 and NTEP approved
- IP66 protection
- Available with metric and UNC threads
Options
- ATEX, FM and IECEx approvals available
Parameter Value Unit Rated capacity (kg) 7, 10, 15, 20, 30, 50, 75, 100 kg NTEP/oiml accuracy class NTEP | Non-Approved | C3 Max. no. of intervals (n) 4000 single | 1000 | 3000 Rated output R.O 2.0 mV/V Rated output tolerance 0.2 ±%mV/V Zero balance 0.2 ±%FSO Creep error 0.0015 | 0.0500 | 0.0200 ±%FSO Temp. effect on sensitivity 0.0030 | 0.0100 | 0.0023 ±%FSO/F Temp. effect on min dead load output 0.0008 | 0.0030 | 0.0010 ±%FSO/F Ultimate over load 300 % of R.C Excitation voltage 10 VDC or VAC RMS Max. excitation voltage 15 VDC or VAC RMS Input resistance 385±15 Ω Output resistance 350±3 Ω Insulation resistance >2000 MΩ Environmental protection IP66 - FSO – Full Scale Output
- All specifications subjects to change whithout notice.
Application
- Demanding environment small platforms
- Demanding environment check weighing
