1000kg Load Cell – SQB Single-Ended Beam Load Cell
$726.00
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | $721.00 |
| 11 - 15 | $10.00 | $716.00 |
| 16 - 20 | $15.00 | $711.00 |
Payment Methods:
Description
High-Performance, Durable Load Cell for Multi-Cell Weighing Applications
The 1000kg Load Cell – SQB Single-Ended Beam by Celtron is engineered for precision and reliability in low-profile platform scales, small tank scales, and other multi-cell applications. Designed for demanding industrial environments, this load cell offers high side-load tolerance and robust construction, ensuring accurate measurements under challenging conditions.
Key Features & Benefits:
- Capacity: 1000kg (available in 250–5000kg variants)
- Construction: Electroless nickel-plated alloy tool steel for superior durability and corrosion resistance
- High Side-Load Tolerance: Maintains accuracy even under uneven loading conditions
- Applications: Perfect for multi-cell configurations in platform scales and small tanks
- Safety & Approval: FM approved for industrial safety standards
Ideal Applications:
- Low-profile platform scales
- Small tank weighing systems
- Multi-cell industrial weighing setups
Smart Tip: SQB load cells deliver reliable and precise performance even in challenging industrial environments, making them a go-to solution for engineers and scale manufacturers.
Description
Model SQB is a single-ended shear beam load cell designed for multiple cell applications, such as low profile platform or small tank scales, when used with proper mounting accessories.
It is insensitive to side loading and capable of reversed loading. Models SQB and SQB-F are constructed of alloy steel and fully potted with special chemical compounds to IP67 to protect the cell from water and moisture damage.
Features
- Capacities: 500 to 20k lbs., 250 to 5000 kg
- High side-load tolerance
- Electroless nickel-plated-alloy tool steel
- NTEP Class III 5000M for SQB, SQB-F and SQB-SS available from 1k to 10k lbs.
- SQB-SS stainless-steel construction
Options
- FM approval
- EDOC product appearance will differ from the photograph due to coating
Certifications
| Parameter | Value | Unit | |
|---|---|---|---|
| Rated capacity (kg) | 250, 500, 1000, 1500, 2000, 2500, 5000 | kg | |
| Rated capacity (lbs) | 500, 1k, 2k, 2.5k, 3k, 4k, 5kSE, 5k, 10k, 15k, 20k | lbs | |
| NTEP/oiml accuracy class | NTEP III | Non-Approved | |
| Max. no. of intervals (n) | 3000 single, 5000 multiple | 1000 | |
| Rated output R.O | 3 | mV/V | |
| Rated output tolerance | 0.25 | ±%mV/V | |
| Zero balance | 1 | ±%FSO | |
| Non-repeatability | 0.020 | 0.020 | ±%FSO |
| Creep error | 0.025 | 0.030 | ±%FSO |
| Ultimate over load | 300 | % of R.C | |
| Excitation voltage | 10 | VDC or VAC RMS | |
| Max. excitation voltage | 15 | VDC or VAC RMS | |
| Input resistance | 385±5 | Ω | |
| Output resistance | 350±3 | Ω | |
| Insulation resistance | >5000 | MΩ | |
| Environmental protection | IP67 | ||
- FSO – Full Scale Output
- All specifications subjects to change whithout notice.
Applications
- Truck/rail scales
- Silo/hopper/tank weighing
- Platform scales (multiple load cells)
- Pallet truck scales
- Packaging machines
