Model MDB Miniature Double-Ended Beam
The Celtron Model MDB miniature double-ended beam load cell offers IP67 protection, RS485/RS422 digital output, and high-side load tolerance—ideal for truck scales, weighbridges,Silo/hopper/tank weighing, and industrial silo weighing with long-range signal transmission and surge protection.
$448.49
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | $443.49 |
| 11 - 15 | $10.00 | $438.49 |
| 16 - 20 | $15.00 | $433.49 |
Payment Methods:
Description
Title :- Model MDB Miniature Double-Ended Beam
Brand :- Celtron
DESCRIPTION
The Model MDB is designed for truck and rail scales in high capacities with low profile. The “load-ball” design means the model is insensitive to side load forces. The Model MDB is constructed of alloy steel and is fully potted and sealed with special chemical compounds to IP67, providing excellent protection against water and moisture attack. With hermetic sealing, the MDB is rated for IP68 providing excellent protection against corrosive and wash-down environments.
FEATURES
• Capacities: 10–50 t
• High side load tolerance
• Electroless nickel-plated alloy tool steel
• Surge protection optional for 10 t to 50 t
• Optional
– Hermetically sealed version available
– FM approval available
APPLICATIONS
• Truck/rail scales
• Silo/hopper/tank weighing
