Model CSP Compression Load Cell
Explore Revere CSP multi-column (MCL) compression load cells, stainless steel load cells (SSLC), road and rail weighbridges (RWBs), silo and hopper weighing (SHW), process weighing (PW), OIML R-60 certified (OIML), NTEP class IIIL load cells, hermetically sealed load cells (IP66/IP68/IP69K), surge protection load cells (SPLC), and ATEX and FM certified load cells for reliable, accurate measurements in industrial applications.
Price range: $630.65 through $2,341.00
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | - |
| 11 - 15 | $10.00 | - |
| 16 - 20 | $15.00 | - |
Payment Methods:
Description
Title :- Model CSP Compression Load Cell
Brand :- Revere
DESCRIPTION
The Model CSP is a multi-column, low profile, stainless steel compression load cell. The unique four column design offers excellent insensitivity to eccentric loads while maintaining accuracy.
This product is suitable for use in road and rail weighbridges and process weighing applications.
The fully leak-tested welded construction, advanced cable entry, and built-in surge protection tubes ensure that this product can be used successfully in demanding
environments.
This product meets the stringent Weights and Measures requirements throughout Europe.
FEATURES
• Capacities: 10–100 t
• Low profile, multi-column stainless steel construction
• Hermetically sealed, IP66, IP68, and IP69K
• Certified to OIML R-60, 4000d and NTEP class IIIL
10000 divisions
– Model CSP offers klb capacity, imperial thread and
NTEP approval
– Model CSP-M offers metric capacity, thread and OIML
approval
• Built-in surge protection tubes (GDTs)
• Current calibration output (SC version) ensures easy
and accurate parallel connection of multiple load cells
• Optional
– ATEX and FM certified versions are available for use in
potentially explosive atmospheres
– Multi-interval and multiple range versions available
– Imperial capacities (25k, 50k, 100k, 200k lbs) not
OIML approved
APPLICATIONS
• Truck and rail weighbridges
• Silo and hopper weighing
• Process weighing
