Model 9103 Double-Ended Beam Load Cell
The Revere Model 9103 Double-Ended Beam Load Cell is a high-capacity (5k-150k lbs), stainless steel, NTEP-certified shear beam load cell with IP67 sealing. Ideal for weighbridges, platform scales, tank & silo weighing, it offers FM & ATEX approval for explosive environments.
Price range: $234.61 through $492.29
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | - |
| 11 - 15 | $10.00 | - |
| 16 - 20 | $15.00 | - |
Payment Methods:
Description
Title :- Model 9103 Double-Ended Beam Load Cell
Brand :- Â Revere
DESCRIPTIONÂ
Model 9103 is a double-ended, center-loaded shear beam type load cell constructed of stainless steel.
This product is suitable for tank weighing systems, low-cost weighbridges and axle weighers.
A reliable sealing is ensured by the proprietary TRANSEAL potting compound and additional mechanical protection of the strain gage area.
A specially-designed mounting arrangement is available, providing the ideal solution for vessel/tank weighing.
FEATURES
• Capacities: 5k to 150k lbs
• Low-profile construction
• Stainless-steel construction
• Certified to NTEP class IIIL, 10000 divisions
• Sealing: IP67 (DIN 40.050)
• Optional
– FM Approved and ATEX & UKCA certified versions for
use in
potentially-explosive atmospheres
– EDOC option available; product appearance will differ
from the photograph due to coating
APPLICATIONS
• Platform scales
• On-board weighing
• Weighbridges
• Silo hopper weighing
