Model 363 Universal Load Cell
The Tedea-Huntleigh Model 363 S-Type Load Cell is a high-precision, nickel-plated universal load cell (50-10k kg) for industrial weighing. Ideal for suspended hoppers, track scales & force measurement, it features IP65 sealing, NTEP certification & FM approval for explosive environments.
Price range: $79.50 through $456.40
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | - |
| 11 - 15 | $10.00 | - |
| 16 - 20 | $15.00 | - |
Payment Methods:
Description
Title :- Model 363 Universal Load Cell
Brand :- Â Tedea-Huntleigh
DESCRIPTION
Model 363 is a multi-purpose nickel-plated S-Type load cell which can be used in tension or compression.
This product is suitable for a wide range of hybrid scales, overhead track scales, belt scales, and process weighing applications.
Reliable sealing is ensured by the proprietary TRANSEAL potting compound and additional mechanical protection of the strain gage area.
FEATURES
• Capacities: 50 to 10000 kg (50 to 20k lbs)
• Nickel-plated steel construction
• Certified to NTEP class III 3000d and class IIIL 10000d
• Suitable for compression and tension applications
• Trimmed output versions available
• Sealing: IP65
• Optional
– FM approved for use in potentially explosive atmospheres
APPLICATIONS
• Suspended hoppers
• Overhead track scales
• Force measurement
