Model 60058 Double-Ended Shear Beam Load Cell

Title :- Model 60058 Double-Ended Shear Beam Load Cell

Brand :- Sensortronics

DESCRIPTION

The Model 60058 is a mid to high capacity nickel-plated alloy steel, double-ended shear beam load cell.

This product is designed for use in industrial and out door environments. Nickel plated steel construction limits corrosion from outdoor use. The IP67 sealing makes it suitable for applications that are subject to high-pressure wash down. Tank weighing is made simple when this load cell is combined with the EZ mount mounting hardware it was designed for. Its high accuracy and availability in high capacities make it ideal for certified truck and rail scales.

This load cell is rated intrinsically safe by the Factory Mutual System (FM); making it suitable for use in potentially explosive environments. This load cell is certified for Legal For Trade applications by the American NTEP standards.

FEATURES

• Rated capacities of 5,000 to 100,000 pounds,
2.3 to 45 metric tonnes
• High quality alloy tool steel construction
• Nickel plated for outstanding corrosion resistance
• Replacement for RTI model 5103 (EZM1)
• Integral conduit adaptor
• Sensorgage™ sealed to IP67 standards
• Factory Mutual System Approved for Classes I, II, III;
Divisions 1 and 2; Groups A through G.
Also, non-incendive ratings (No barriers!)
• Optional
– EDOC option available; product appearance will differ
from the photograph due to coating

APPLICATIONS

• Tank, bin, and silo weighing
• Railroad track scales
• Truck scales
