Model 1250 – Aluminum High Capacity Single-Point Load Cell
Tedea-Huntleigh Model 1250 Aluminum Single-Point Load Cell – OIML R60 & NTEP approved, IP65/IP67 rated for industrial weighing. Ideal for large platform scales, bench & floor scales, check weighing, and hazardous area applications. FM & EEx ia IIC T4 approved
Price range: $159.14 through $329.37
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | - |
| 11 - 15 | $10.00 | - |
| 16 - 20 | $15.00 | - |
Payment Methods:
Description
Title :- Model 1250 – Aluminum High Capacity Single-Point Load Cell
Brand :- Tedea-Huntleigh
DESCRIPTION
The Model 1250 is a single-point load cell designed for direct mounting of large platforms.
This product is a cost-effective load cell for use on counting, weighing, bench or floor scale products.
This high accuracy load cell is approved to OIML R60, NTEP and other stringent approval standards. Suitable for use in hazardous environments, this load cell can be provided with European approval to EEx ia IIC T4 and are FM approved to class I, II, III, Division I.
A special humidity-resistant protective coating assures long-term stability over the entire compensated temperature range.
The two additional sense wires, sample the bridge supply voltage at the load cell. Complete compensation of change in the lead wires resistance, due to temperature change and/or cable extension, is achieved by feeding his voltage into the appropriate electronics.
FEATURES
• Capacities 50–1500 kg
• Aluminum construction
• Single-point 800 x 800 mm platform
• OIML R60 and NTEP approved
• IP65 protection
• Available with metric and UNC threads
• Optional
– EEx ia IIC T4 hazardous area approval
– FM and IECEx approvals available
– IP67 option available
APPLICATIONS
• Large platform scales
• Hanging scales
• Check weighing
