Model 1130 – Stainless Steel Single-Point Load Cell

Title :- Model 1130 – Stainless Steel  Single-Point Load Cell

Brand :- Tedea-Huntleigh

DESCRIPTION

Imagine a product that can transform your weighing experience introducing is a low profile stainless steel single point load cell ideally designed for direct mounting in bench and platform scales, packaging and process weighing equipment, and is built to perform in demanding environments.

What makes the Model 1130 so special?  Its small size The small physical size, combined with high accuracy and  low cost, makes this load cell ideally suited for low profile bench and counting scales. A special humidity resistant protective coating assures long-term stability over the entire compensated temperature range.

Built from durable stainless steel, the Model 1130 is recognized by some of the most stringent international approval standards, including OIML and NTEP. This guarantees you are investing in a product that meets the highest global standards for performance.

But there’s more. This load cell comes with two additional sense wires that allow it to feed back the actual voltage reaching it, ensuring complete compensation for changes in lead resistance whether due to temperature shifts or cable extension. This means you get reliable, consistent results, no matter the conditions.

Key Features:

• Capacities: Ranging from 7 to 100 kg, tailored to your specific needs.
• Stainless Steel Construction: Built for durability in the toughest environments.
• Single-Point Design: Supports platforms up to 400 × 400 mm.
• Global Approvals: OIML R60 and NTEP certified, ensuring top-tier accuracy.
• Protection Level: Rated IP66, offering resistance against dust and water.
• Flexibility in Threads: Available with both metric and UNC threading options.
• Optional Certifications: Need extra safety? It’s available with ATEX, FM, and IECEx approvals.

APPLICATIONS

• Demanding environment small platforms
• Demanding environment check weighing
