Model 1022 Single-Point Aluminum Load Cell
The Tedea-Huntleigh Model 1022 Single-Point Load Cell is a high-accuracy (3–200 kg), low-profile aluminum load cell with IP66 protection. OIML & NTEP approved, it’s perfect for retail, bench scales, grocery & retail weighing, and compact platforms, offering a cost-effective solution for precise
Price range: $43.66 through $92.77
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | - |
| 11 - 15 | $10.00 | - |
| 16 - 20 | $15.00 | - |
Payment Methods:
Description
Title :- Model 1022 Single-Point Aluminum Load Cell
Brand :- Tedea-Huntleigh
DESCRIPTION
The Model 1022 is a low profile single-point load cell designed for direct mounting in low cost weighing platforms.
Its small physical size, combined with high accuracy and aluminum construction, makes this low cost load cell ideally suited for retail, bench and counting scales.
Using Model 1022 load cells simplifies scale construction, which results in significant parts and labor savings.
The Model 1022 is available in a range of capacities: from 3 to 150 kg, approved to OIML R60 (4000d); to 20 to 150 kg, approved to OIML R60 (6000d); to 3 to 100 kg, approved to NTEP (5000d, single). Environmental protection to IP66 is provided as standard. For hazardous environments, ATEX approved versions are available.
FEATURES
• Capacities: 3–200 kg
• Only 22 mm high
• Aluminum construction
• Single-point 350 x 350 mm platform
• IP66 protection
• OIML R60 and NTEP approved
• Optional
❍ ATEX, FM and IECEx approvals available
❍ Symmetric configuration available
APPLICATIONS
• Bench scales
• Counting scales
• Grocery scales
