3510 Stainless Steel Shear Beam Load Cell – 500 kg | Rugged, Reliable, and Precision-Driven
$363.00
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | $358.00 |
| 11 - 15 | $10.00 | $353.00 |
| 16 - 20 | $15.00 | $348.00 |
Payment Methods:
Description
Built for Durability in Harsh Industrial Environments
The 3510 Stainless Steel Shear Beam Load Cell (500 kg) by Tedea-Huntleigh represents the gold standard in industrial-grade weighing technology. Designed for long-lasting performance in hostile environments, this load cell combines robust stainless steel construction with OIML R60 and NTEP approval, ensuring accurate, stable measurements even under challenging conditions.
Perfect for platform scales, process weighing systems, and tank applications, the Model 3510 offers a dependable, low-profile solution trusted across industries where precision meets performance.
Technical Specifications
- Model: 3510
- Capacity: 500 kg (range: 300–5000 kg)
- Construction: Stainless Steel
- Design Type: Shear Beam Load Cell
- Finish: Polished Stainless
- Output: Standard Product
- Accuracy / Class Code: OIML 3000 d
- Environmental Protection: IP68 equivalent (fully welded and moisture resistant)
- Brand: Tedea-Huntleigh
- SKU: 03510-500K-C3-01X
- Availability: In Stock
- Approval / Safety Code: Not ATEX/FM approved
Why Choose the 3510 500 kg Shear Beam Load Cell?
When weighing precision meets rugged design, the Tedea-Huntleigh 3510 stands out. Its stainless-steel construction ensures corrosion resistance and durability, while the OIML and NTEP certifications validate its performance accuracy. The low-profile architecture makes it ideal for compact and high-traffic weighing setups, delivering consistent reliability day after day.
Key Advantages
- High-precision weighing across multiple industrial applications
- Fully welded stainless-steel body for superior environmental protection
- Compatible with platform, process, and tank scales
- Excellent load stability and repeatability
- Designed for harsh washdown and outdoor use
Applications
- Platform and floor scales
- Hopper and tank weighing
- Conveyor and batching systems
- Process automation setups
- Industrial washdown areas
Smart Tip
If you’re looking for complementary load cells and weighing accessories, check out
Load Cell Solutions Australia and
Load Cell Shop — trusted DoFollow resources for professional-grade weighing solutions.
Description
The Model 3510 provides the weighing industry with the ultimate protection necessary for today’s hostile environments in an economical, low-profile range suitable for platform scale manufacture.
Its low profile and fully welded sealing combined with high accuracy makes this load cell ideally suited for low profile platforms, pallet truck weighers, tanks and silos.
The guide slots incorporated into the upper and lower mounting faces enable manufacturers to easily position the load cell.
Hermetically sealed against moisture, the construction of the Model 3510, in combination with a polyurethane dual shielded cable, enables continuous operation in demanding environments while maintaining a high operating specification.
The two additional sense wires feedback the voltage reaching the load cell. Complete compensation of changes in lead resistance, due to temperature change and/or cable extension, is achieved by feeding this voltage into the appropriate electronics.
Features
- Capacities 300–5000 kg, 1000–5000 lbs
- Stainless steel construction
- OIML R60 and NTEP approved
- Hermetically sealed to IP68 and IP69K
- Specially designed for demanding environments
Options
- EEx ia IIC T6 hazardous area approval
- FM and IECEx approvals available
- 1100Ω impedance available
| Parameter | Value | Unit |
|---|---|---|
| Rated capacity (kg) | 300, 500, 750, 1000, 1200, 2000, 3000, 5000 | kg |
| Rated capacity (lbs) | 1000, 1500, 2500, 4000 | lbs |
| NTEP/oiml accuracy class | NTEP | Non-Approved | C3 | C6 | |
| Max. no. of intervals (n) | 3000 single, 5000 multiple | 1000 | 3000 | 6000 | |
| Rated output R.O | 2.0 for kg and 3.0 for lbs | mV/V |
| Rated output tolerance | 0.1 | ±%mV/V |
| Zero balance | 2 | ±%FSO |
| Creep error | 0.0200 | 0.0500 | 0.0200 | 0.0100 | ±%FSO |
| Temp. effect on sensitivity | 0.0023 | 0.0100 | 0.0023 | 0.0007 | ±%FSO/F |
| Temp. effect on min dead load output | 0.0010 | 0.0030 | 0.0010 | 0.00058 | ±%FSO/F |
| Ultimate over load | 300 | % of R.C |
| Excitation voltage | 10 | VDC or VAC RMS |
| Max. excitation voltage | 15 | VDC or VAC RMS |
| Input resistance | 380±10 | Ω |
| Output resistance | 355±5 | Ω |
| Insulation resistance | >2000 | MΩ |
| Environmental protection | IP68, IP69K |
- FSO – Full Scale Output
- All specifications subjects to change whithout notice.
Application
- Low profile platforms
- Pallet truck weighing
- Tank and silo weighing
- Demanding environment weighing
- Food industry weighing
