Title :- Model ASC Compression Load Cell
Brand :- Revere
DESCRIPTION
The Model ASC is a single column, stainless steel compression load cell.
This product is suitable for use in road and rail weigh bridges and process weighing applications.
The welded construction and built-in surge protection ensure that this product can be used successfully in harsh environments.
This load cell meets the stringent Weights and Measures requirements throughout Europe and the USA
FEATURES
• Capacities: 30, 40, 50, and 60 t
• Self-aligning, stainless steel single column
• Hermetically sealed, IP66/IP68/IP69K
• Certified for OIML R60 C6 and NTEP class IIIL 10000
divisions
• Built-in surge protection tubes (GDTs)
• Current calibration output (SC) ensures easy and
accurate parallel connection of multiple load cells
• Optional
❍ Digital version available (model DSC)
APPLICATIONS
• Weighbridges
• Silo hopper weighing
