Model 240 Fluid-Damped Single-Point Load Cell
The Tedea-Huntleigh Model 240 High-Speed Load Cell is a precision, fluid-damped single-point load cell with IP66 sealing for washdown applications. Ideal for check weighing, multi-head filling, grading & sorting machines, it’s OIML R60 & NTEP certified for dynamic weighing & automation.
Price range: $261.55 through $942.48
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | - |
| 11 - 15 | $10.00 | - |
| 16 - 20 | $15.00 | - |
Payment Methods:
Description
Title :- Model 240 Fluid-Damped Single-Point Load Cell
Brand :- Tedea-Huntleigh
DESCRIPTION
The Model 240 is specifically designed to be used where the fast acquisition of a stable load signal is paramount. The Model 240’s unique fluid damping system allows the load cell to be used in applications that previously required the use of LVDT’s or similar measuring devices.
The Model 240 brings load cell adaptability into check weighing and grading applications.
Approved to OIML R60 and NTEP standards, sealed to IP66 level and available in coated steel or stainless steel, the Model 240 is suitable for most wash-down applications.
The two additional sense wires feed back the voltage reaching the load cell. Complete compensation of changes in lead resistance due to temperature change and/or cable extension, is achieved by feeding this voltage into the appropriate electronics.
FEATURES
• Capacities 2–50 kg
• Painted steel construction
• OIML R60 and NTEP approved
• IP66 protection
• Available with metric and UNC threads
• Optional
❍ Stainless steel construction
APPLICATIONS
• Multi-head filling machines
• Check weighing
• Grading machines
• Liquid filling
• Dynamic weighing
