ASC2 Compression Load Cell
Revere Model ASC2 Compression Load Cell – Stainless-steel single-column compression load cell, IP66, IP68, IP69K rated, OIML R60 & NTEP certified, self-aligning design, ideal for weighbridges, truck scales, rail weighing, heavy-duty industrial weighing, Process weighing, and hazardous environments. Fully welded & surge-protected for harsh conditions.
Price range: $385.25 through $445.22
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | - |
| 11 - 15 | $10.00 | - |
| 16 - 20 | $15.00 | - |
Payment Methods:
Description
Title :- ASC2 Compression Load Cell
Brand :- Revere
DESCRIPTION
The Model ASC2 is a single column, stainless steel compression load cell fully compatible with original Model ASC.
This product is suitable for use in road and rail weighbridges and process weighing applications.
The fully welded construction and built-in surge protection ensures that this product can be used successfully in many demanding environments.
This load cell meets the stringent Weights and Measures requirements throughout Europe and the Americas.
FEATURES
• Capacities: 30, 40 and 50 t
• Self-aligning, stainless steel single column
• Hermetically sealed, IP66/68/69K
• Certified to OIML R60 5500d and NTEP IIIL/10,000 d
• Built-in surge protection
• Current calibration output ensures the easy and
accurate parallel calibration of multiple load cells
• Compatible with original Model ASC
• Optional
– Digital version available (Model DSC2)
– ATEX and IECEx approvals available
APPLICATIONS
• Weighbridges
• Process weighing
