7kg Load Cell – Model 9010 Self-Contained Weighing Module
$2,074.18
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | $2,069.18 |
| 11 - 15 | $10.00 | $2,064.18 |
| 16 - 20 | $15.00 | $2,059.18 |
Payment Methods:
Description
Fast, Reliable, and Shock-Resistant Weighing Solution
The 7kg Load Cell – Model 9010 Self-Contained Weighing Module from Tedea-Huntleigh is engineered for applications requiring fast weighing and settling times, even under repeated shock or impact loading. Ideal for multihead weighers, check weighers, and dynamic industrial weighing systems, this module delivers accurate, stable, and repeatable measurements in demanding environments.
Key Features & Benefits:
- Capacity: 7 kg (available in 3–90 kg variants)
- Self-Contained Design: Combines load cell and weighing module for simplified installation
- Adjustable Tare Load Cancelling: Ensures high accuracy even under variable conditions
- Highly Effective Viscous Damping: Reduces oscillation for faster and precise readings
- Environmental Protection: IP65 rated – protected against dust and low-pressure water jets
- Precision Engineering: Ideal for static and dynamic weighing applications with sudden or impact loads
Applications:
- Multihead weighers
- Check weighers
- Dynamic industrial weighing systems with impact or shock loading
Limitations:
- Not ATEX/FM approved – unsuitable for explosive or hazardous environments
Smart Tip: The Model 9010 is perfect for applications needing a robust, high-speed weighing module that maintains accuracy under repeated shock or fast-loading conditions.
Description
The Model 9010 is a self-contained weighing module for use in repeated shock-loading applications or where fast weighing and settling times are required, such as multihead weighers, check weighers and other static and dynamic weighing applications characterized by sudden or impact loading.
The Model 9010’s unique fluid damping system allows the load cell to be used in applications that previously required the use of LVDT’s or similar types of measuring devices.
The Model 9010 has a unique adjustable tare load cancellation feature which brings load cell adaptability into check weighing and grading applications.
The two additional sense wires feedback the voltage reaching the load cell. Complete compensation of changes in lead resistance, due to temperature change and/or cable extension, is achieved by feeding this voltage into the appropriate electronics.
Features
- Capacities 3–90 kg
- Unique adjustable tare load cancelling mechanism
- Highly effective viscous damping
- 6 Built-in overload limit stops in three directions
- Weighing speed is much faster than standard load cell
- IP65 protection
Options
- Stainless steel version
- IP66 with additional breather tube
- OIML and FM approvals available
| Parameter | Value | Unit |
|---|---|---|
| Rated capacity (kg) | 3, 5, 7, 10, 15, 20, 30, 50, 90 | kg |
| Max. no. of intervals (n) | 3000 | |
| Rated output R.O | 2.0 | mV/V |
| Rated output tolerance | 0.2 | ±%mV/V |
| Temp. effect on sensitivity | 0.002 | ±%FSO/F |
| Temp. effect on min dead load output | 0.004 | ±%FSO/F |
| Excitation voltage | 10 | VDC or VAC RMS |
| Max. excitation voltage | 15 | VDC or VAC RMS |
| Input resistance | 415±15 | Ω |
| Output resistance | 350±5 | Ω |
| Insulation resistance | >5000 | MΩ |
| Environmental protection | IP65 |
- FSO – Full Scale Output
- All specifications subjects to change whithout notice.
