500kg Load Cell – RLC Ring Torsion Load Cell | High-Performance Industrial Precision
$829.72
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | $824.72 |
| 11 - 15 | $10.00 | $819.72 |
| 16 - 20 | $15.00 | $814.72 |
Payment Methods:
Description
Compact, High-Accuracy Load Cell for Torsion Applications
The 500kg Load Cell – RLC Ring Torsion Load Cell from Revere is a low-profile, stainless-steel torsion load cell designed for high-precision measurement in industrial applications. Its compact ring design makes it ideal for rotary or torsional measurement, and it is engineered to deliver accurate and reliable results even under challenging conditions.
With hermetic sealing and IP66/IP68 environmental protection, the RLC load cell ensures stable, long-term performance in both static and dynamic weighing applications.
Technical Specifications
- Model: RLC Ring Torsion Load Cell
- Capacity: 500 kg (Range: 250 kg to 60 t)
- Material: Stainless Steel
- Design: Ring torsion type, low-profile
- Cable Length: 5 m
- Accuracy / Class Code: OIML 3000 d
- Mounting Thread Type: TH
- Output: Standard Product
- Environmental Protection: IP66 and IP68 (IP69K optional for select models)
- Brand: Revere
- SKU: 00RLC-500K-C3-00X
- Approval / Safety Code: Not ATEX/FM approved
- Stock Status: In Stock
Why Choose the 500kg RLC Ring Torsion Load Cell?
The RLC 500kg load cell combines high-accuracy torsional measurement with robust stainless-steel construction, making it ideal for industrial, manufacturing, and automated weighing applications. Its hermetic sealing ensures protection against dust, moisture, and harsh environments, while the low-profile ring design allows for easy integration into compact systems.
Key Benefits
- High-precision measurement for torsion or rotary applications
- Durable stainless-steel housing for corrosion resistance
- Hermetically sealed with IP66/IP68 protection
- Compact, low-profile design for versatile mounting
- Reliable output with OIML 3000 d accuracy
Applications
- Rotary and torsion measurement systems
- Industrial machinery and automation
- Force measurement in robotic systems
- Process weighing and torque monitoring
- High-precision load measurement in tight spaces
Smart Tip
Explore complementary products and high-quality load cells at:
Load Cell Solutions Australia
Load Cell Shop
For accessories, digital indicators, or mounting kits, visit Sensors and Gauges.
Description
The RLC is a low profile, high-performance stainless-steel ring torsion type load cell.
The fully welded construction and glass-to-metal cable entry ensure that this product can be used successfully in harsh environments found in the food, chemical and allied process industries.
This product is suitable for small and medium platform scales, hoppers and process weighing.
This product meets the stringent Weights and Measures requirements throughout Europe and USA.
Features
- Capacity range: 250 kg to 60 t
- Low profile, stainless steel construction
- Hermetically sealed, IP66 and IP68; IP69K is available for 250 kg, 5 t and 10 t versions
- Meets OIML R-60 and NTEP 6000d
- Outputs are matched to ensure easy and accurate parallel connection of multiple load cells
Options
- ATEX certified versions are available for use in potentially explosive atmospheres
- Multi-interval and multiple-range versions are available
| Parameter | Value | Unit |
|---|---|---|
| Rated capacity (kg) | 0.25t, 0.5t, 1t, 2t, 3.5t, 5t, 10t, 28t, 60t | kg |
| NTEP/oiml accuracy class | NTEP IIIL | D3 | C3 | C6 | |
| Max. no. of intervals (n) | 10000 | | 3000 | 6000 | |
| Rated output R.O | 2 (1.75 for 0.25 t, 2.05 for 10 t) | mV/V |
| Zero balance | 1.0 | ±%FSO |
| Creep error | 0.0245 | 0.0123 | ±%FSO |
| Temp. effect on sensitivity | (0.0010) | (0.0010) | 0.0070 0.0045 | ±%FSO/F |
| Temp. effect on min dead load output | (0.0008) | (0.0008) | 0.0050 | 0.0025 | ±%FSO/F |
| Ultimate over load | 300 | % of R.C |
| Excitation voltage | 5 – 15 | VDC or VAC RMS |
| Max. excitation voltage | 30 | VDC or VAC RMS |
| Input resistance | 1110±50 (1100±50 for 0.25t and 10t) | 1075±100 for 28t | 1350±100 for 60t | Ω |
| Output resistance | 1025±25 (1025±50 for 0.25t and 10t) | 930±0.5 for 28t | 1175±0.5 for 60t | Ω |
| Insulation resistance | ≥5000 (20 for 28 and 60 t) | MΩ |
| Environmental protection | IP66 and IP68; IP69K available for 250 kg, 5t and 10t |
- FSO – Full Scale Output
- All specifications subjects to change whithout notice.
| Parameter | Value | Unit |
|---|---|---|
| Rated capacity (kg) | 0.25t, 0.5t, 1t, 2t, 3.5t, 5t, 10t, 28t, 60t | kg |
| NTEP/oiml accuracy class | NTEP IIIL | D3 | C3 | C6 | |
| Max. no. of intervals (n) | 10000 | | 3000 | 6000 | |
| Rated output R.O | 2 (1.75 for 0.25 t, 2.05 for 10 t) | mV/V |
| Zero balance | 1.0 | ±%FSO |
| Creep error | 0.0245 | 0.0123 | ±%FSO |
| Temp. effect on sensitivity | (0.0010) | (0.0010) | 0.0070 0.0045 | ±%FSO/F |
| Temp. effect on min dead load output | (0.0008) | (0.0008) | 0.0050 | 0.0025 | ±%FSO/F |
| Ultimate over load | 300 | % of R.C |
| Excitation voltage | 5 – 15 | VDC or VAC RMS |
| Max. excitation voltage | 30 | VDC or VAC RMS |
| Input resistance | 1110±50 (1100±50 for 0.25t and 10t) | 1075±100 for 28t | 1350±100 for 60t | Ω |
| Output resistance | 1025±25 (1025±50 for 0.25t and 10t) | 930±0.5 for 28t | 1175±0.5 for 60t | Ω |
| Insulation resistance | ≥5000 (20 for 28 and 60 t) | MΩ |
| Environmental protection | IP66 and IP68; IP69K available for 250 kg, 5t and 10t |
- FSO – Full Scale Output
- All specifications subjects to change whithout notice.
Application
- Platform scales
- Belt scales
- Silo hopper weighing
