5000kg Load Cell – RLC Ring Torsion Load Cell | Industrial High-Precision Force Measurement
$959.36
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | $954.36 |
| 11 - 15 | $10.00 | $949.36 |
| 16 - 20 | $15.00 | $944.36 |
Payment Methods:
Description
Robust, Low-Profile Stainless-Steel Load Cell for Torsional Applications
The 5000kg Load Cell – RLC Ring Torsion Load Cell from Revere is a low-profile, high-performance stainless-steel torsion load cell engineered for industrial and process applications requiring precise torsional and rotary force measurement. Its compact ring design allows integration into rotary systems, robotic setups, and automated processes, delivering consistent, reliable measurements under demanding conditions.
Hermetically sealed with IP66/IP68 protection, this load cell ensures durability and stable performance in harsh environments, including exposure to moisture, dust, and process chemicals.
Technical Specifications
- Model: RLC Ring Torsion Load Cell
- Capacity: 5000 kg (Range: 250 kg to 60 t)
- Material: Stainless Steel
- Design: Ring torsion, low-profile
- Cable Length: 5 m
- Accuracy / Class Code: OIML 3000 d
- Mounting Thread Type: TH
- Output: Standard Product
- Environmental Protection: IP66 and IP68 (IP69K optional for select models)
- Brand: Revere
- SKU: 00RLC-005T-C3-00X
- Approval / Safety Code: Not ATEX/FM approved
- Stock Status: In Stock
Why Choose the 5000kg RLC Ring Torsion Load Cell?
The RLC 5000kg load cell combines high-precision torsional measurement with durable stainless-steel construction, making it ideal for industrial machinery, robotics, and automation systems. Its hermetically sealed IP66/IP68 housing provides long-lasting protection against harsh environments, while the low-profile design ensures easy installation in compact spaces without compromising accuracy.
Key Benefits
- Accurate torsional and rotary force measurement
- Stainless steel housing for superior corrosion resistance
- Hermetically sealed with IP66/IP68 protection
- Compact, low-profile design for versatile mounting
- Reliable OIML 3000 d output
Applications
- Industrial rotary and torsion systems
- Robotics and automation
- Process weighing and force monitoring
- High-precision torsion measurement
- Equipment requiring compact and durable load cells
Smart Tip
Complement your load cell system with trusted solutions from:
Load Cell Solutions Australia
Load Cell Shop
For accessories, indicators, and mounting kits, visit Sensors and Gauges.
Description
The RLC is a low profile, high-performance stainless-steel ring torsion type load cell.
The fully welded construction and glass-to-metal cable entry ensure that this product can be used successfully in harsh environments found in the food, chemical and allied process industries.
This product is suitable for small and medium platform scales, hoppers and process weighing.
This product meets the stringent Weights and Measures requirements throughout Europe and USA.
Features
- Capacity range: 250 kg to 60 t
- Low profile, stainless steel construction
- Hermetically sealed, IP66 and IP68; IP69K is available for 250 kg, 5 t and 10 t versions
- Meets OIML R-60 and NTEP 6000d
- Outputs are matched to ensure easy and accurate parallel connection of multiple load cells
Options
- ATEX certified versions are available for use in potentially explosive atmospheres
- Multi-interval and multiple-range versions are available
| Parameter | Value | Unit |
|---|---|---|
| Rated capacity (kg) | 0.25t, 0.5t, 1t, 2t, 3.5t, 5t, 10t, 28t, 60t | kg |
| NTEP/oiml accuracy class | NTEP IIIL | D3 | C3 | C6 | |
| Max. no. of intervals (n) | 10000 | | 3000 | 6000 | |
| Rated output R.O | 2 (1.75 for 0.25 t, 2.05 for 10 t) | mV/V |
| Zero balance | 1.0 | ±%FSO |
| Creep error | 0.0245 | 0.0123 | ±%FSO |
| Temp. effect on sensitivity | (0.0010) | (0.0010) | 0.0070 0.0045 | ±%FSO/F |
| Temp. effect on min dead load output | (0.0008) | (0.0008) | 0.0050 | 0.0025 | ±%FSO/F |
| Ultimate over load | 300 | % of R.C |
| Excitation voltage | 5 – 15 | VDC or VAC RMS |
| Max. excitation voltage | 30 | VDC or VAC RMS |
| Input resistance | 1110±50 (1100±50 for 0.25t and 10t) | 1075±100 for 28t | 1350±100 for 60t | Ω |
| Output resistance | 1025±25 (1025±50 for 0.25t and 10t) | 930±0.5 for 28t | 1175±0.5 for 60t | Ω |
| Insulation resistance | ≥5000 (20 for 28 and 60 t) | MΩ |
| Environmental protection | IP66 and IP68; IP69K available for 250 kg, 5t and 10t |
- FSO – Full Scale Output
- All specifications subjects to change whithout notice.
Application
- Platform scales
- Belt scales
- Silo hopper weighing
