22000kg Load Cell – Model 98001 Low Profile Universal Load Cell
$1,037.15
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | $1,032.15 |
| 11 - 15 | $10.00 | $1,027.15 |
| 16 - 20 | $15.00 | $1,022.15 |
Payment Methods:
Description
High-Capacity, Versatile Load Cell for Precision Testing Applications
The 22000kg Load Cell – Model 98001 is a universal low-profile alloy steel shear beam load cell designed for applications that require both tension and compression loading, making it ideal for testing machines and heavy-duty industrial applications. Built for durability and precision, this load cell delivers reliable and accurate measurements even under demanding conditions.
Download Data Sheet
Key Features & Benefits:
- Capacity: 22,000 kg (available in 0.5–100 t variants)
- Construction: Alloy steel with nickel-plated finish for maximum durability and corrosion resistance
- Universal Design: Supports both tension and compression loading for versatile applications
- Cable Length: 6 m – flexible installation options
- Loading Thread: MT – easy and secure mounting
- Output: 2.0 mV/V – provides consistent signal for accurate measurements
- Environmental Protection: IP67 rated for dust-tight and water-resistant operation
- Precision Engineering: Ideal for testing machines, heavy industrial scales, and high-capacity weighing
Applications:
- Testing machines requiring tension and compression loading
- Heavy-duty industrial weighing systems
- High-capacity process and platform scales
Limitations:
- Not ATEX/FM approved – unsuitable for explosive or hazardous environments
Smart Tip: The Model 98001 is perfect for industrial setups demanding a versatile, high-capacity load cell capable of handling both tension and compression.
Description
The Model 98001 is a universal alloy steel shear beam load cell ideal for testing machine applications employing both tension and compression loading.
This shear beam design load cell provides excellent immunity to impact and side forces. This load cell includes integrated overload protection for compression loading applications.
Features
- Capacity: 0.5–100 t
- Alloy steel construction
- Universal load cell
- Integrated overload protection (in compression)
- Tension and compression loading
Options
- Model 98005 without base mounting plate (for compression applications only)
- Metric and imperial threads
| Parameter | Value | Unit |
|---|---|---|
| Rated capacity (kg) | 500, 1k, 2k, 3k, 5k, 10k, 15k, 20k, 25k, 30k, 40k, 50k, 60k, 100k | kg |
| Rated output R.O | 2.0 | mV/V |
| Rated output tolerance | 10 | ±%mV/V |
| Zero balance | 1 | ±%FSO |
| Non-repeatability | <0.020 | ±%FSO |
| Creep error | <0.002 | ±%FSO |
| Ultimate over load | 300 | % of R.C |
| Excitation voltage | 10 | VDC or VAC RMS |
| Max. excitation voltage | 15 | VDC or VAC RMS |
| Input resistance | 699–750 | Ω |
| Output resistance | 699–750 | Ω |
| Insulation resistance | >1000 | MΩ |
| Environmental protection | IP67 |
- FSO – Full Scale Output
- All specifications subjects to change whithout notice.
Application
- Universal testing machines
